| Measuring Range | 0-25% |
| Accuracy 1 | +/-2% of Full Scale |
| Signal Output 2 | 295 – 625 uA |
| Linearity | +/-2% of Full Scale |
| Response T90 | 7 sec |
| Temp Coefficient | un-compensated |
| Operating Temp | 0 to 45°C |
| Recommended Storage 3 | 0 to 25°C |
| Temperature Coefficient | Compensated |
| Shelf Life 4 | 6 months |
| Humidity Non-condensing | 0-99% RH |
| Expected Life | 18-24 months |
| Warranty 5 | 12 months |
| Electrical Connector | 2 Ring Gold Disk |
Related products
-
Oxygen Analyzers
Ntron Sil02-LT Oxygen Analyzer
Features
- Analyser and sensor meets the requirements of Sil02-LT
- Easy to read display of measured oxygen levels
- Push button calibration
- 2 Configurable alarm outputs
- Long life Zirconia sensor
- Analogue output with RS485 option included.
- Plug connector interface wiring terminals
SKU: n/a -
Oxygen Analyzers
AII GPR-1500 Series Oxygen Analyzer
Features
- General purpose or intrinsically safe (ATEX) models
- Measuring range: 0-10, 0-100, 0-1000 ppm, 0-1%, (0-25%)
- Accuracy: <2%
- Fast recovery from exposure to air
- Measure in pure CO2 with XLT sensor
- Two alarms with GPR-1500A analyzer model
- XLT oxygen sensor
- Indoor or outdoor applications
SKU: n/a -
-
Oxygen Analyzers
AII GPR-2000 Oxygen Analyzer
Features
- Measuring range: 0-1%, 0-5%, 0-10%, 0-25%
- 24 to 32 months sensor life span (in normal use)
- Internal pump option
- 0 to 1V output
- General purpose or intrinsically safe (ATEX) models
- 0.5 to 1.0 l/m (1 to 2 SCFH) flow rate
- XLT sensor options for CO2 backgrounds
- Lightweight: 2.5Kgs
- 1/8 in compression tube fittings
SKU: n/a
